Standard Features
DM series 230 psi ductile iron diaphragm valves in valve nest configuration
Stager Control with 6-day timer
100 psi epoxy lined and coated carbon steel vessels
EE series – PVC external brine ejector
Fixed rate external backwash rate of flow controllers.
Accumaticä Brine System.
Resin - Polystyrene 8% DVB CL
PVC header and lateral internals
Brine distribution header
110V, 60Hz, 1Ø
Options
ASME code tanks
7-day timer
Demand initiation
Twin configuration with stagers and timers
Twin Alternating with WK520, PWS series meter, stagers and ARC timers
Pressure gauge and test tap kit
Skid mounting
220V, 50Hz, 1Ø
Operating Conditions
25 to 100 psi 100°F
